Promac PBD-2140V Economical Bench Lathe

Promac PBD-2140V Economical Bench Lathe

Stock Code: PBD-2140V
MPN: PBD-2140V
£1,923.25 (exc VAT) per 1
£2,307.90 (inc VAT)
Quantity: - +

Promac PBD-2140V Economical Bench Lathe

Promac PBD-2140V Economical Bench Lathe grey cast iron frame for vibration-free machining. Electronic variable speed control. Automatic longitudinal feed. CW/CCW rotation of the spindle enables threads to be realized. Lathe chuck protection, emergency stop switch.


Specifications:

Motor (V/kW) 230/1.1

Center height (mm) 105

Center distance (mm) 450

Swing over bed (ø-mm) 210

Swing over carriage (ø-mm) 135

Spindle bore (mm) 21

Morse taper of headstock MT3

Speed range (min-1) 50 1’250/100–2’500

Cross slide, stroke (mm) 100

Top slide, stroke (mm) 75

Range of metric threads (mm) 0.25 3.0

Range of inch threads (TPI) 8 24

Longitudinal feed (mm/U) 0.045/0.125

Morse taper of tailstock MT2

Morse taper of tailstock, stroke (mm) 40

Max. tool size (mm) 10

3-jaw chuck (mm) 100

Dimensions (mm) 1’000×550×400

Weight (kg) 94

MPNPBD-2140V
BRANDPromac
WEIGHT94 kgs
ConditionNew
