308020-0200 HMT VersaDrive M20 Oversized Galv. ImpactaTap

HMT Versadrive impactatap quick threading M20 galvernised impact tap from Wasp Supplies Ltd

308020-0200 HMT VersaDrive M20 Oversized Galv. ImpactaTap

£73.65 £88.38 (inc. VAT) RRP: £86.65

Produces a M20 x 2.5mm oversize thread to compensate for galvanised coatings.

This product qualifies for free shipping to

UK Mainland Excluding Scottish Highlands.

Description

HMT VersaDrive ImpactaTap® M20 x 2.5mm galvanising impact tap produces an oversize thread, perfect for use prior to sending steelwork to the galvernisers, the oversized thread then compensates for the increased thickness the coating produces on galvernised steelwork and galvernised fixings.

VersaDrive galvernising impact taps can be used with an impact wrench and taps holes up to 15 times faster than when using a hand tap wrench, the Holemaker Technology (HMT) VersaDrive system allows the tapping bit to be used not only in an impact wrench but also in any reversible drill with a 1/2" chuck and any hand tap wrench. The video below shows how versatile these metal cutting taps can be :-
.

Versadrive Impacta Galv taps

Extremely Fast tapping with minimal kickback, specially hardened for Impact wrench use.
Chipbreaker action for automatic chip clearance when impact tapping
Unique dual point starting angle for easy alignment and fast cut.
Very high grade tool steel, with ground flutes for high accuracy and long life
Goldmax low-friction titanium coating to stop heat burn-out
High strength, non slip shank design
Oversize thread to compensate Galvernized coatings.

Part No	M Thread size & Pitch	L mm	I1 mm	Tap hole size (metric coarse thread)	Shank mm	Minimum torque to tap 20mm steel
308020-0050	M5 x 0.80 (+0.15")	55	18	4.2mm	11	200 Nm
308020-0060	M6 x 1.0 (+0.15")	55	20	5.0mm	11	240 Nm
308020-0080	M8 x 1.25 (+0.15")	60	22	6.8mm	11	280 Nm
308020-0100	M10 x 1.5 (+0.15")	70	24	8.5mm	11	300 Nm
308020-0120	M12 x 1.75 (+0.15")	80	29	10.2mm	11	320 Nm
308020-0160	M16 x 2.0 (+0.15")	90	32	14.0mm	11	360 Nm
308020-0200	M20 x 2.5 (+0.15")	100	37	17.5mm	11	400 Nm
308020-0240	M24 x 3.0 (+0.15")	110	45	21.0mm	11	600 Nm
